Model Number: JR210-SC
JR210-SC Hotline Telephone for Taxi Server is designed to be an emergency call box and coated eye-catching housing color.
The telephone will accept incoming calls and relies on external equipment to control calling.
Main Features of Hotline Telephone for Taxi Server
Product Description
| Casing Material | Stainless steel body |
| Colors | Red, other colors to special order |
| Handset Material | ABS material handset with stainless steel spiral cord |
| Keypad | Hotline phone, No keypad |
| Temperature | Operating: -30°C to +65°C
Storing: -40°C to +75°C |
| Weather Resistance | IP65 |
| Ringing Tone | Shrill warble tone 80 dBA at 1 metre typical |
| Hook Switch | Electronic / magnetic with no visible moving parts |
| M.T.B.F. | Calculated to have an M.T.B.F. in excess of 50,000 hours using |
| Weight | Up to 4 kg depending on option |
Technical Specification
| Analogue Version | |
| Power Supply | From the analogue telephone network |
| Supply Voltage | 24 VDC to 65 VDC |
| Supply Current | 20 mA DC to 100 mA DC |
| Ringer Volume | – 80dB(A) at a distance of 1 m – 110dB(A) at a distance of 1 m (for external horn speaker) |
| Dialing Method | DTMF mode in accordance with ITU-T recommendation Q.23. |
| SIP Version | |
| Power Supply | PoE or 12V DC |
| Power Consumption | -Idle:1.5W -Active:1.8W |
| SIP Protocol | SIP 2.0 (RFC3261) |
| Support Codec | G.711 A/U, G.722 8000/16000, G.723, G.729 |
| Communication Type | Full duplex |
| Ringer volume | – 90~95dB(A) at a distance of 1 m – 110dB(A) at a distance of 1 m (for external horn speaker) |
| Ambient conditions | |
| Protection type | IP 66 as per EN60529 |
| Operating temperature | -40°C to +70°C |
| Storage temperature | -45°C to +85°C |
Applications
JR210-SC Hotline Telephone for Taxi Server more commonly used in parking lots, prisons, railway/metro platforms, hospitals, police stations, ATM machines, stadiums, outside building etc.
Packing & Delivery
| Unit Size | 204 *339 *196 (mm) |
| Carton Size | 200 *300 *440 (mm) |
| Packaging Materials | Pearl cotton, carton |
| Net Weight | 5 KG |
| Gross Weight | 6 KG |
| Port | Shenzhen, Guangdong | |||
| Lead Time
(If you finish the payment today, your order will ship out within the delivery date.) |
Quantity(Sets) | 1 | 2-500 | >500 |
| Est. Time(Days) | 2 | 5 | To be negotiated | |
Our Company
J&R Technology offers a wide variety of special telephones and unique customs services to customers. Our telephone is suitable for all IP systems, and we have provided many customers with excellent emergency system solutions and customized telephone service, which is very mature in the manufacturing of the telephone.
Customized Accessories
J&R provide LOGO printing and accessories customization services.
We will also provide suitable solutions according to the needs of customers.
HOOK FUNCTION: Magnetic hooks for choice
KEYBOARD SHAPE: Round buttons and square buttons for choice
INDICATOR LAMP COLOR: Red, yellow, blue, green for choice
MOTHERBOARD MODEL: 2G/3G/4G/SIP/GSM for choice
HADSET CORD: Black curly handset cord or stainless steel spiral cord
If you have any custom requirements, please feel free to contact us.
